Uht Flavoured Milk Pasteurized Milk Filling Sealing Machines BW-2500
View Large
Product Name : Uht Flavoured Milk Pasteurized Milk Filling Sealing Machines BW-2500
Product Origin : China
Product Category : Liquid Filling Machine
More Products : Click here!
Contact Details : Shenyang Beiya Beverage Machinery Co.,Ltd
Product Code : BW-2500
Product Details

 BW-2500 type Uht Flavoured Milk/ Pasteurized Milk Filling Sealing Machines is automatic with top configuration. The entire machine is made of 304 food-grade stainless steel, and the surface is special processed to be beautiful.




1. Work flow:



Put cardboard into carton holder (manually) --- Bottom preforming --- Bottom heating and sealing --- Ultrasonic capping (Optional) --- Filling --- Top preforming --- Top heating and sealing --- Date printing --- Finished product



The whole process is controlled by PLC, and only need one person to operate.



2. Suitable for filling:



Various kinds of dairy products, such as milk, yogurt, cream, soy milk, beaten egg, etc.



3. Technical parameter:

1. Capacity: 250--1000ml (can be filled by one machine)

2. Output: 1800-2500 cartons/hour

3. Packing material: Cardboard carton / aluminium foil carton

4. Capping: With capping (Optional)

5. Shelf life: Milk, yogurt: 7--21days ( 2-6 degC storage)

6. Filling temperature: 2-50 degree centigrade

7. Overall power: 25KW (three phases of electricity)

8. Compressed air pressure: 1.0-1.4 Mpa, Flow rate: 1.4-2M3/min, without oil, water and dust

9. Cooling water: Flow volume: ≥ 40L/ min Temperature: ≤ 30 degC

10. Size: (L*W*H): 3.7m*1.6m*2.8m Net Weight: 3500kg

11. Installation requirement: Any smooth floor, such as cement, floor tile, plastic ground, etc. Do not need to make angle.
