当你购买了福禄克287记录万用表TrendCapture功能+的FlukeView®Forms软件一起保存。

最大限度地利用组合福禄克287和FlukeView Forms软件组合套件生产力。

专为从事研发，维修，制造和电子电路或系统的设计，今天的专业人士。

带有内置数据记录器和TrendCapture功能的 能力，在287帮助你跟踪难以捉摸的，间歇性问题或监测设备，其任何职能。

FlukeView Forms软件使您能够记录存储和分析个别读数或测量系列，覆盖记录数据，以寻找因果关系，或者把你的数据转化为有意义的图形和表格的专业报告。

287/ FVF组合套件为您提供了实用和实惠的方式来记录电路设计的性能。

===================================================

Key Features Include:

New with V 1.1 Upgrade! Zoom on trend provide unprecedented ability to view analyze TrendCapture data; see detail at X5 magnification.

New with V 1.1 Upgrade! Simplified Record screen when setting up recording

New with V 1.1 Upgrade! Logging function with expanded memory for unattended monitoring of signals over time. Using on-board TrendCapture users can graphically review logged readings without needing a PC. Store up to 15,000 recorded events.

Large 50,000 count, ¼ VGA display with white backlight. Multiple sets of measurement information can simultaneously be displayed at the same time.

Logging function with TrendCapture is an essential tool for documenting the performance of your designs, processes or systems, or unattended monitoring while you work on other projects. It plots measurements as a single line to help detect signal anomalies over time. Using on-board TrendCapture, you can graphically view logged readings without a PC. (Software and interface cable optional).

Log multiple sessions or log data continuously for over 200 hours.

i-info button. On board help screens for measurement functions. Unsure about a function? Go to that function and Press the “i” button.

Now, name your saved measurements and also recall measurements made in the field

Real Time Clock – for automatic time stamping of saved readings

Field upgradeable and expandable meter lets you stay current as new capabilities are added

Multi-lingual interface

Min/Max/Average with Time Stamp to record signal fluctuations

Soft keys, scroll buttons and easy navigation control access to secondary functions.

0.025% Basic DC accuracy

100 kHz ac bandwidth

True-rms ac voltage and current for accurate measurements on complex signals or non-linear loads.

Measure up to 10A (20 A for 30 seconds; 10A continuous)

100 mF capacitance range

Temperature function

Relative mode to remove test lead resistance from low ohms or capacitance measurements

Peak capture to record transients as fast as 250 μs

Premium test leads and alligator clips included

Optional FlukeView forms enables you to document, store and analyze individual readings or a series of measurements, then convert them into professional-looking documents

Optional magnetic hanger allows you to hang the meter for easy viewing while freeing your hands to focus on the job.

Limited lifetime warranty

CAT III 1000 V / CAT IV 600 V safety rated
