This is semi-automatic double loop wire binding machine used on automatic precutting wire-O which be packed in spool,

inserting to the book, and closing the wire-O, insert calendar hanger, saving enormous labor force, and reducing waste of

double loop wire in maximum, widely used for loose leaf book binding of notebook, diary, desk/wall calendar, and etc.

The machine adopts imported advanced motor device for more accurate and steady rotation.

Adopted touch screen and PLC imported from Siemens of Germany, and steam components from Taiwan.

Specification:

Feeding Mode: Manual

Handling of Double Wire (automatic cutting, insertion & closing)

Wire Specifications Diameter: 1/4-3/4, Pitch: 2:1, 3:1

Books thickness: 3/16-9/16

Max. Paper Length: 520mm

Max. Binding Width: 507mm

Min. Paper Length: 75mm

Working Speed (Books/H): 1000-1200

Power Supply: 220V/1ph/50Hz

Air Compressor (not included): 1.5KW

Air Pressure: 6-8bar

Machine Dimensions (W*D*H): 1030*770*1200mm

Net Weight (excl. power pack): 220kgs

Dimension of Py-off Unit: 490*760*1200mm

Weight of Py-off Unit: 65kgs
