Fluke 717 Pressure Calibrators

The Fluke 717 Pressure Calibrators delivers outstanding performance, durability and reliability. These calibrators are compact, lightweight, and easy to carry.

With a push button interface similar to the multifunction Fluke 740 Series Documenting Process Calibrators, the 717s are easy to use.

They are EMI tolerant, dust and splash resistant, and feature a removable battery door for quick battery changes.

These calibrators come in 9 models measuring pressure up to 5000 psi/345 bar and are compatible with Fluke 700Pxx differential, gauge and absolute pressure modules to increase functionality.

------------------------------------------------------------------------------------------------------------------------------------------------

Features at a Glance



    Measure pressure, 0.05% of full scale with internal sensor up to 5000 PSI/345 bar sensor (5000G model)



    Measure mA with 0.015% accuracy and 0.001 mA resolution, while sourcing 24V loop power



    Measure pressure to 10,000 psi/700 bar using one of 29 Fluke 700Pxx Pressure Modules



    1/8 NPT female pressure fitting



    Compatible with non-corrosive Gases and liquids



    Select eleven different engineering units



    Zero, min, max, and hold functions



    Calibrate P/I instruments with simultaneous pressure and current measurement



    Pressure switch test function captures set, reset and Deadband values of a pressure switch



    Error% calculation of mA measurements for quick pass-fail decisions



    Long lasting battery life



    Holster features test lead storage



    Compatible with Toolpack magnetic hanging system



    New switch test
