Product Name : | Aly006 Pan Tilt HD 720P Indoor Wifi bgn p2p H.264 Onvif IP Camera support TF card |
| Product Origin : | China | |
| Product Category : | Network/IP cameras | |
| More Products : | Click here! | |
| Contact Details : | Shenzhen Alytimes Technology Co., LTD | |
| Product Code : | aly006 |
Product Details
| Features: 1: Plug &Play (P2P): Plug and Play, No need DDNS, No need Port Forwarding. 2: Easy Operation: Network connection no need PC. You can easily realize all the function via the APP. 3: Doorbell : Support Wireless Doorbell, ( press doorbell, camera sound" Dinddong") 4: Onvif: Support Onvif Protocol, Support NVR (above Onvif version 2.4.2) 5: TF Card:Support TF card, up to 128GB.( only support FAT32 file system), Support remote playback. (Note: 32GB TF card can be recorded up to 15 days.) 6: Alarm: Support Wireless Detector Alarming, Such as: Work with smoke detector, door sensor, Infrared sensor(up to 64-channel wireless detector), Phone push alarm,Email alarm.Whistle alarm. | ||
| Model No.: Aly006 | ||
| System | Main Processor | Hisilicon processor,built-in ARM9 and a high-speed video co-processor. |
| Operating system | Embedded Linux OS | |
| Image Sensor | Sensor | High Definitioin Color CMOS Sensor |
| Display Resolution | 1280*720 (1.0 Megapixel) | |
| Min.Illuminatioin | 0.1 Lux / F1.2 (With IR Illuminator) | |
| lens | Lens Type | Glass Lens |
| Lens Parameter | Focal Length:3.6 mm; Aperture:F 2.4 | |
| Angle of View | 65° | |
| Video | Image Compression | H.264. |
| Image Frame Rate | 30fps maxmium, downward adjustable | |
| Resolution | 720P(1280 x 720), VGA(640 x 360), QVGA(320 x 180) | |
| Image Adjustment | Automatic | |
| Flip Mirror Image | Automatic (Built-in gravity sensing system, Auto filp mirror image) | |
| Infrared Mode | Automatic | |
| Pan/Tilt Angle | Horizontal:355degree & Vertical: 90degres | |
| Night Visibility | 11pcs IR-LEDs, night vision range up to 8 metres | |
| Filter Switch(IR-Cut) | Built-in IR Cut, no color deviation indoor or outdoor. | |
| Audio | Coding Standards | G.711A. |
| Input / Output | Supports two-way audio, Built-in Mic & Speaker | |
| Record | TF Card Record | Support 128G TF card.( only support FAT32 file system) |
| Record Mode | Alarm Record; Motion Detection Alarm Record; Timing video; Manual Record. | |
| Record Standard | VGA @ 25 fps | |
| Playback | Support remote playback. | |
| Network | Ethernet | RJ-45 Ethernet |
| Wireless | Standard IEEE 802.11 b/g/n, Security support :WEP, WPA, WPA2 Encryption. | |
| Online Visitor | Online Visitor LAN support 10 people, WAN support 5 people. | |
| Onvif | Support Onvif Protocol, Support NVR (above Onvif version 2.4.2) | |
| Alarm | Alarm | Supports Motion detection Alarm, Linkage Alarm(up to 64-channel wireless detector), Phone push alarm, Email alarm. Whistle alarm. |
| Others | Product Type | Plastic/ Indoor Use |
| DC Power | DC5V/2A.. | |
| Working Temperature | 0~55 °C | |
| Working Humidity | 10%- 90% RH | |
| Size | Item size: 103mmx102.6x 122mm (LxWxH) | |
| Packaging size:182mmx110mmx149mm(LxWxH) | ||
| Weight | N.W.:280g G.W.: 550g (Note:Actual Weight Final) | |
| Accessories | Adaptor, User Manual, Bracket,Screw. | |
| System Required | SmartPhone & TablePC | Support iOS and Android system, Provide free App "APCam" |
| PC | Only support remote monitor on Internet Explorer(IE) browser. | |
| Certification | CE,FCC,RoHS | |
| Warranty | Limited 2-Year Warranty | |
